Tianfei high-tech CTF002 Motorized Valves
CTF002 Series: Water Treatment Electric Valve Actuators
Tianfei High-Tech’s CTF-002 series offers specialized motorized valves designed for water treatment applications. These electric valves combine high torque with compact design for reliable performance in demanding environments.
| モデル | CTF-002 |
| 電圧 | AC220V |
| Motor Power | 14W |
| 動作電流 | 150だがしかし |
| 中温度 | 0-50℃ |
| 出力トルク | 20ニューメキシコ州 |
| バルブ材質 | ステンレス鋼; UPVC;CPVC;Cast Iron; Cast Steel |
| 使用圧力 | 0-1.6メガパスカル |
| バルブサイズ | DN15-DN50 |
| 開閉時間 | 10-12S |
優れたエンジニアリング設計
CTF002 electric valve actuators use nylon housing and machined gears. This ensures light weight and smooth operation. These motorized ball valves provide large output torque (20ニューメキシコ州) with low noise. A transparent window allows visual position monitoring. The double sealing structure achieves IP65 protection.
Flexible Installation and Operation
These CTF002 motorized ball valves support multiple connection types. Options include thread, union, and flange ends. Quick assembly requires no special tools. The design allows both electric and manual operation. This ensures continuity during power failures or maintenance.
Technical Performance
Operating at AC220V/14W, the valve draws 150mA current. It handles pressures to 1.6MPa within 10-12 秒. Suitable for 0-50°C environments, these 2 way motorized valves come in UPVC, CPVC, and metal materials. Sizes range from DN15 to DN50.
Water Treatment Applications
These motorized valves excel in:
-
Pure water and raw water pipelines
-
Drainage and sewage systems
-
Saltwater and seawater applications
-
Acid-base chemical solution handling
-
Food industry compatible fluid control
Corrosion Resistance and Durability
The valve body resists corrosion from various media. Materials include stainless steel, cast iron, and plastics. This makes these motorized valves suitable for aggressive environments. Their wear-resistant design ensures long service life.
Industrial Valve
The CTF-002 series provides optimal solutions for water projects. These 2 way electric valves offer precise flow control in treatment processes. Their combination of reliability and adaptability makes them ideal for modern water infrastructure.
